Sectional Model 2732

Duty Rating: Medium-Duty
Insulation/R-Value: 9.4
Layers: 3
Warranty: 10-Year
Price: $$

download brochure

Sectional Model 2732

Solid steel construction is the basis for the Amarr 2732. Two tough steel skins with CFC-free polystyrene insulation, and a thermal break creates a barrier to keep heat and cold from transferring through the door. The ideal choice for International Energy Conservation Code (IECC)/insulated door projects that are budget sensitive and do not require a 24-gauge exterior.

RAPID INSTALL VERTICAL LIFT

Time is money! Designed for Amarr commercial warehouse and dock doors; saves approximately 20 minutes installation time.

ECO-FRIENDLY

Our polystyrene insulation is free of Ozone depleting Chlorofluorocarbons (CFC) while providing efficient insulation to help reduce the negative environmental impact of heating and cooling energy use.

Section Profile
Ribbed Stucco
Construction
Triple Layer Construction Triple Layer Steel Insulation Steel
Windows
Window Panel Option - 24x12 24″ x 12″ Insulated
Commercial Garage Door Window Option 24x6 24″ x 6″ Double Insulated Acrylic
Available Colors
  • True White
  • Commercial Brown
  • Sandtone
  • Commercial Gray



Specifications
R-VALUE 9.4
STEEL THICKNESS 27/27 Ga.
PANEL DESIGN Pencil Groove
STEEL EMBOSSMENT Stucco
CONSTRUCTION LAYERS Three
MAX STD WIDTH 24’2″
MAX STD HEIGHT 26’1″
DOOR THICKNESS 2″(5.1cm)
